Trustfire D3R Professional Mountain Bike and Road Bike Headlight
Trustfire D3R Professional Mountain Bike and Road Bike Headlight
D3R BICYCLE LIGHT
The D3R is a professional mountain bike and road bike headlight suitable for high-intensity long-distance riding users.
MAXIMUM
Lumens:1350
MAXIMUM
Meters:110
PRODUCT FEATURES
1. Using internationally patented LED, the service life can reach 50,000 hours
2. Luminous flux up to 1350LM, range up to 110 meters
3. One-button dimming, high, medium and low three gears
4. Metal body, excellent heat dissipation.
5. The shell is made of aviation aluminum alloy CNC fine processing.
and the surface is anodized
6. Net weight: 142.2 grams, size: 89*32*55mm
D3R+HE08 net weight: 174.6 grams, size: 89*32*94mm
7. Large fioodlight optical system design
8. With low power warning and intelligent temperature control downshift function9. Built-in 3000mAh polymer lithium battery, Type-C direct charging
10.Quick release design, can be adapted to a variety of expansion devices
LIGHTWEIGHT AND PORTABLE EIGHT FUNCTIONS
FEATURES
3000 mAh
IPX6
Reverse charging
Low voltage warning
Type-C charging
Quick release
Smart temperature control
Anti-glare
1350 LUMENS HIGH BRIGHTNESS LAMP BEADS
It uses international patented LED lamp beads, with a service life of up to 50,000 hours;the luminous flux is up to 1350LM and the range is up to 110 meters.
ANTI-GLARE, SAFER NIGHT RIDING
Protect oncoming vehicles and pedestrians from the effects of high beams,making riding safer
Protect oncoming vehicles and pedestrians from the effects of high beams.
making riding safer
D3R headlight: The anti-glare design can control the light within a certain range to effectively eliminate glare and allow you to ride at night with peace of mind.
LARGE FLOODLIGHT, SOFT AND EYE-FRIENDLY
It adopts a 155-degree floodlight optical system design, and the light is soft and not dazzling.
IPX6 WATERPROOF
Regardless of wind or rain, it can still light the way for you in harsh environments.
TYPE-C CHARGING
Supports high current charging recognition, bringing users a faster charging and discharging experience.
REVERSE CHARGING
In the wild, you can charge mobile phones, sports cameras. stopwatches and other devices.
ONE-CLICK CONTROL
Power on/off
In the off state, click the top switch and the power indicator will light upIn the off state, press and hold for 0 5 seconds to turn on the power indicatorand press and hold again for 0.5 seconds to turn off the power.
Gear Switching
When the device is powered on and unlockedclick the medium brightness gear - highbrightness gear - low brightness gearto cycle through the operations.
Lock/Unlock Mode
In the off state, double-click the button to enter the lock mode. In the lock mode, press the buttonto operate.
The light will flash slowly twice and then go out as a reminder. Double-click again to unlock andreturn to normal light.
Mode Switching
When the device is powered on, quickly press the button twice to switch between constant lightmode and flashing mode.
Memory gear
When the flashlight is in any gear, it will automatically memorize the current working gear. Aftershutting down, it will start working in the current memorized gear.Note. Both the common mode and the flashing mode can be memorized.
BATTERY INDICATOR
When the device is turned off, press the top switch and the power indicator light will light up and automatically go out after 2 seconds. Different colors represent different remaining power. The corresponding relationship is shown in the following table:
GREEN:[70%~100%]
YELLOW:[30%~70%]
RED:[15%~30%]
RED FLASHES:[1%~15%]
QUICK ASSEMBLY AND DISASSEMBLY
Insert the headlight into the slot and push the lever to complete.
Push left into the card slot.Move the lever backward.Finish
PRODUCT PARAMETERS
MODEL | LOW LIGHT | MEDIUM LIGHT | HIGH LIGHT | SLOW FLASH | FLASH |
BRIGHTNESS | 120LUMENS | 360LUMENS | 1350 LUMENS | 320 LUMENS | 1350 LUMENS |
RUN TIME | 15.5 HOURS | 5 HOURS | 95 MINUTES | 10 HOURS | 3.5 HOURS |
RANGE | 62 METERS | 265 METERS | 110 METERS | \ | \ |
LIGHT INTENSITY | 256 CD | 2056 CD | 3025 CD | \ | \ |
DROP HEIGHT:1 METERS
WATERPROOF:IPX6
NEARBY FEATURES:INTELLIGENT TEMPERATURE CONTROL, LOW VOLTAGE WARNING
Note:The above parameters are only approximate values, obtained from testing in a laboratory environment, and may change with changes in the usage environment.
